Boeing 737-200 Advanced SN 22628

  • boeing-737-3
  • boeing-737-2
  • boeing-737-1

Price: Sold

Year: 1981
Reg Number: VP-CDA
Serial Number: 22628
Total Time Hours: 7,504 hrs
Status: Sold

Download Brochure

More Information

  • This field is for validation purposes and should be left unchanged.

Highlights

  • Stage 3 modified
  • Auxiliary Fuel Tank(s)
  • Flight Data Recorder
  • SATCOM
  • Airframe Maintenance Program

Airframe

Total Time: 7,504 hrs

Landings: 2,979

Engines

JT8D-17
Left
Right
Total Time
7,504 hrs
7,504 hrs
hrs
hrs
Cycles Since New
2,979hrs
2,979hrs
-
-

Avionics

  • ADF: Dual Collins 51Y-7
  • Autopilot: Sperry SP-77
  • Communication Radios: Dual Collins 618M-5 w/8.33 kHz spacing
  • CVR: Fairchild 93A100-80
  • DME: Dual Collins DME-860-E5
  • EFIS: Universal EFI-890
  • FDR: Fairchild 15630-61
  • Flight Director: Universal EFI-890
  • Flight Rules: IFR
  • FMS: Dual Universal UNS-1F w/GPS
  • GPS: Litton LTN-200-2GNSS
  • Hi Frequency: Dual Collins 628T-1 w/Motorola NA-134D2 SELCAL
  • INS: Dual Litton LTN-92
  • Navigation Radios: Dual Collins 51RV-5 w/FM immunity
  • Radar Altimeter: Dual Collins 860F-4
  • SATCOM: AirCell Axxess dual-channel
  • TAWS: Sundstrand Mark II
  • TCAS: AlliedSignal TCAS-II w/change 7
  • Transponder: AlliedSignal Mode S / Collins 621A-6A Mode C
  • Weather Radar: Sperry Primus 90 color

Additional Equipment

  • Cockpit: Dual Honeywell HG-480-B13 digital air data computers, Lear Siegler performance data computer, Universal multi- function display w/moving map, 406 MHz ELT w/GPS position, laser gyro, Universal Avionics Vision One synthetic vision system, MaxViz 1500 EVS enhanced vision system, Universal Avionics UL-701 datalink, dual Universal radio control units, LNAV enroute & approach modes (coupled)
  • Equipment: Nordam Stage 3 hush kits, PATS 7-tank long-range auxilary fuel tank system (SFAR 88 completed), forward luggage locker, additional insulation package, Med-Air first aid kit, super soundproofing, automatic wheels & brakes, Tempus IC passenger monitoring unit, dual 10-person life rafts, retractable airstair
  • Crew Accessories: Miltope TP-4429 cockpit printer, Universal Avionics application server unit, crew rest/work area, crew lounge (full supine crew bunk), electronic flight bag, refurbished instrument panel
  • Medical: Phillips defribillator, Med Air doctor's kit

Interior

  • Last Done: Synchro Aircraft Interiors, Van Nuys, CA. on 2007
  • Passengers: 24
  • Configuration: VIP
  • General: Fireblocked FAR 25.853 compliant custom interior
  • Seating: Leather seating, 3-place berthable divan, aft lounge area w/4-place fully-reclining club seating & dual berthable divans, new sheepskin crew seats installed as reported 10/11/13, cockpit jumpseat, three flight attendant seats
  • Refreshment Equip: Forward crew galley w/oven, refrigerator & food storage, aft galley w/sink, oven, microwave, refrigerator, freezer, food storage & crystal rack
  • Entertainment Equip: Airshow 410, dual video systems interlinked to three monitors & sound system, office entertainment system, triple Boland flat-screen 21-inch monitors, three DVD players
  • Business Equipment: Private office/lounge w/club seating
  • Accessories: New interior fabrics in 2013, six Water-Guard filtration units
  • Lavatory: Forward crew, mid & aft guest lavs
  • Stateroom/Suite: Miid-cabin private stateroom w/dual beds, nightstand, wardrobe, dedicated entertainment system & private lav w/bidet, vanity & sink

Exterior

  • Last Done: Lufthansa on 1994
  • Colors: White w/red stripe
