Gulfstream G-III SN III-316
Highlights
- RVSM
- Terrain Awareness & Warning System
- Traffic Collision Avoidance System
- Cockpit Voice Recorder
- Flight Data Recorder
- Winglets
- Thrust Reversers
Airframe
Total Time: 14,965 hrs
Landings: 7,238
Engines
Spey MK 511-8
Left
Right
Total Time
13,734 hrs
14,614 hrs
hrs
hrs
Cycles Since New
6,698hrs
7,063hrs
-
-
Avionics
- ADF: Dual Honeywell RNZ-850
- AFIS: Yes
- Altimeter: Standby
- Autopilot: Honeywell SPZ-800
- Avionics Package: Honeywell Primus II
- Communication Radios: Triple Honeywell RCZ-850
- Compass: Standby
- CVR: Fairchild GA100
- DME: Dual Honeywell RNZ-850
- EFIS: Dual Honeywell EDZ-805 5-tube
- FDR: Fairchild F1000
- Flight Director: Dual Honeywell
- Flight Phone: Wulfsberg VI
- FMS: Dual Honeywell FMZ-800
- Hi Frequency: Dual Collins 718U-5 w/Motorola NA-135 SELCAL
- INS: Dual Litton LTN-72
- Navigation Radios: Dual Honeywell RNZ-850
- Radar Altimeter: Dual Honeywell SRZ-850
- TAWS: AlliedSignal Mark V EGPWS
- TCAS: TCAS-2000 w/change 7
- Transponder: Dual Honeywell RCZ-852
- Weather Radar: Honeywell Primus 870
Additional Equipment
- Cockpit: Dual Honeywell AZ-800 air data computers, ELT, angle of attack, elevator trim, airspeed indicator, attitude indicator, OAT, true airspeed/static air temperature indicator, clocks, specific range indicator, vertical speed indicator, VNAV, voice advisory unit, VOR, windshear computer, cabin/engine/pressure indicator panel
- Equipment: Thrust reversers, nosewheel steering, RS & LS generators, dual inverters, standby inverter, dual batteries, fifteen life vests, first aid kit, life raft w/ELT battery, engine fire bottles, speed brakes, wing anti-ice, dual pitot static systems, potable water system, engine chip detector
- Crew Accessories: Crew inertia reel, dual portable Halon fire extinguishers
- Lights: Wing & tail strobes, emergency
Interior
- Passengers: 12
- General: Fireblocked
- Seating: Forward 4-place club seating & dual mid-cabin forward-facing seats, aft 2-place club opposite 4-place berthable divan
- Sidewalls: New wood panels installed 12/09
- Carpet: New carpeting installed 12/09
- Refreshment Equip: Aft galley w/microwave, convection oven & coffeemaker
- Entertainment Equip: Entertainment center w/forward & aft 18-inch flat screen monitors installed 12/09
- Lavatory: Aft
Exterior
- Colors: White w/blue & red stripes
